Application Credentials

Application Credentials allows you to give machine accounts the ability to authenticate against Catalyst Cloud without needing a full user account. Application Credentials can be given the same or a subset of the roles of the user who creates them and an expiry time can be set.

Creating an Application Credential

The openstack command line can be used to create an application credential.

To create a credential with the same roles as your user and with a generated secret then the command openstack application credential create <name> will create one with the given <name>:

$ openstack application credential create cred1
| Field        | Value                                                                                  |
| description  | None                                                                                   |
| expires_at   | None                                                                                   |
| id           | b61580fb52e54909aab3************                                                       |
| name         | cred1                                                                                  |
| project_id   | 22d7e8ec60ec437f8b99************                                                       |
| roles        | project_admin _member_                                                                 |
| secret       | dqRk13A5HdekIyZAEdVoi9UjvvMvYkKgnRq16CwtG1VB86CLnkfkktkCGrYexkFwZFh1CPt3hDqwv5X3p6iing |
| unrestricted | False                                                                                  |

The option --secret is used to specify the secret.

The option --role can be used multiple times to define the roles assigned to the credential.

The option --description sets a description for the credential.

The option --expiration sets an expiry time, in UTC, for the credential. If this is not given then the credential does not expire.

$ openstack application credential create cred2 --secret mysupersecret --description "Ansible CICD User" \
  --role _member_ --expiration "2024-03-08T00:00:00"
| Field        | Value                            |
| description  | Ansible CICD User                |
| expires_at   | 2024-03-08T00:00:00.000000       |
| id           | 342ddaab6f7643a5a60b80f8d727bd97 |
| name         | cred2                            |
| project_id   | 22d7e8ec60ec437f8b99************ |
| roles        | _member_                         |
| secret       | mysupersecret                    |
| unrestricted | False                            |

Using an Application Credential

Once the Application Credential is created then it can be used to authenticate against Catalyst Cloud. Instead of providing a user name and password the machine user can authenticate using the application credential ID and secret.

For example the following lists the servers running in the project:

$ openstack server list --os-auth-url  \
  --os-application-credential-secret mysupersecret \
  --os-application-credential-id 342ddaab6f7643a5a60b80f8d727bd97 \
  --os-auth-type v3applicationcredential

You can also obtain an authentication token and use that for further operations:

$ openstack token issue --os-auth-url \
  --os-application-credential-secret mysupersecret \
  --os-application-credential-id 342ddaab6f7643a5a60b80f8d727bd97  \
  --os-auth-type v3applicationcredential

The application credential can be used in the clouds.yaml file:

    auth_type: v3applicationcredential
      application_credential_id: 342ddaab6f7643a5a60b80f8d727bd97
      application_credential_secret: mysupersecret
    region: nz-por-1
    identity_api_version: 3


If you want to restrict the roles that the application credential has then we need to specify the role by the following names:


Name in the Openstack command

Project admin


Project moderator


Project Member


Heat stack owner


Compute start/stop


Object storage


Auth only


You can only give roles to an application credential that your user already has. Even if the role you have has a super set of the permissions the role you want the application credential to have, if the role is not assigned to your user you can’t give it to the application credentials you create. For example, if you have the _member_ role you can’t create a credential with the compute_start_stop role even though the _member_ role has all of the permissions in the compute_start_stop role, you would need to give assign your user the compute_start_stop role first.

If you try to create an application credential with roles that you do not have then the openstack command will return an error:

$ openstack application credential create cred6 --secret mysupersecret /
  --description "Ansible CICD User" --role _member_ --role heat_stack_owner
Invalid input for field 'roles/1/id': 'heat_stack_owner' does not match '^[a-zA-Z0-9-]+$'

Failed validating 'pattern' in schema['properties']['roles']['items']['properties']['id']:
    {'maxLength': 64,
     'minLength': 1,
     'pattern': '^[a-zA-Z0-9-]+$',
     'type': 'string'}

On instance['roles'][1]['id']:
    'heat_stack_owner' (HTTP 400) (Request-ID: req-c0fd3576-e95e-4bd1-a247-466c72392de8)

Rotating an Application Credential

To rotate an Application Credential the process is as follows. First create a new application credential with a new name and new secret, then update the application’s configuration to use the new Application Credential. Once all applications are using the new credential then you can deleted the old application credential.
